GE TJD422400WL Circuit Breaker
The GE TJD422400WL is a 400 A, 2-pole thermal magnetic molded case circuit breaker designed for 240 VAC/250 VDC systems. It features a robust construction with lugs for secure connections and reliable performance. Ideal for industrial and commercial applications, this breaker ensures protection against overloads and short circuits, offering durability and safety in demanding environments.
Features
- Trip Mechanism: Non-interchangeable trip for consistent and reliable protection.
- Current Rating: Standard continuous current rated for stable performance.
- Installation: Suitable for reverse feed applications.
- Device Line: Includes thermal magnetic molded case circuit breakers and molded case switches.
- Lugs: Equipped with Cu/Al line and load lugs for versatile wiring compatibility.
Specifications
| Frame: | Q |
| Number of Poles: | 2 |
| Phase: | 1 |
| Trip Type: | Long Time and Instantaneous |
| Voltage Rating: | 240 VAC/250 VDC |
| Standard & Approvals: | UL E11592 Listed |
| Amperage Rating: | 400 A |
| Dimensions: | 10-1/8 in (Height) x 8-1/4 in (Width) x 3-13/16 in (Depth) |
| Type: | Type TJD Thermal Magnetic |
| Interrupt Rating: | 22/10 kA |
| Connection Type: | Cable-In/Cable-Out (Lug-Lug) |
