The GE THHQB21100 is a compact circuit breaker designed for residential and commercial applications. This 2 pole breaker has a current rating of 100 Amp and is suitable for 120/240V systems. It features a bolt-on connection for secure mounting to bus connections in load centers and lighting panels. This thermal-magnetic breaker provides reliable protection against overcurrents and short circuits with an interrupting capacity of 22 kA. It includes quick-make/quick-break mechanisms and a common trip bar. This breaker is also suitable for reverse feed applications and is UL Listed and HACR rated.
Features
- Electrical Protection: Overcurrent, Short circuit
- Voltage Rating: 120/240 VAC
- Current Rating: 100 Amps
- Pole Configuration: 2
- Mounting Style: Bolt-On
- Interrupting Rating: 22 kA
- Trip Type: Thermal Magnetic, Long-Time and Instantaneous Trip
- Special Features: Quick-make/quick-break mechanisms, Common trip bar, Suitable for Reverse Feed
- Compliance: UL Listed, HACR rated
