GE ABB - Bolt On Circuit Breaker - 3 Pole 240V AC - THHQB32015

The GE THHQB32015 is a 3-pole, bolt-on circuit breaker designed for commercial and light industrial applications. This compact, thermal-magnetic breaker provides reliable overload and short-circuit protection for 240V AC systems. With a 15A current rating and 22 kA interrupting capacity, it ensures dependable performance in demanding panelboard installations. The bolt-on mounting design offers a secure, vibration-resistant connection, while the quick-make/quick-break mechanism and common trip feature enhance safety and operational reliability. The breaker is UL Listed and suitable for reverse feed applications.

Features

• Electrical Protection: Provides overcurrent and short circuit protection.
• Voltage Rating: Suitable for 240V AC systems.
• Current Rating: Features a 15A capacity.
• Number of Poles: 3-Pole configuration.
• Mounting Type: Bolt-on design for secure installation.
• Interrupting Rating: Has a high interrupting capacity of 22 kA at 240V AC.
• Trip Type: Thermal Magnetic trip mechanism with Long-Time and Instantaneous (LI) functions.
• Wire Compatibility: Accepts copper wire sizes from 14 to 8 AWG and aluminum wire sizes from 12 to 8 AWG.
• Safety Features: Includes quick-make/quick-break mechanisms and a common trip bar.
• Reverse Feed: Suitable for reverse feed applications.
